F8 Aluminum Octocopter Robot

Flat-8 custom frame drone of 8 inches triblade props

Aluminium F8 Octocopter

Aluminium F8 Octocopter

Aluminium F8 Octocopter

The aluminum F8 flat octocopter represents a rugged, highly modular approach to custom drone design. Measuring arround 620mm diagonally from motor to motor hub; this platform utilizes a custom-fabricated aluminium chassis instead of standard molded polyamide or carbon fiber plates.

The flat-8 octocopter is assembled with eight 2807 brushless motors, a 6S LiPo battery, and a F422 flight controller with two integrated ESCs mounted inside the aluminum frame. This aluminum profile frame and motors setup can handle a payload of around 5 kg and offers an efficient thermal heatsink. The frame is coated with electrostatic paint to prevent short circuits and is isolated using several soft silicone dampening pads to minimize vibrations reaching the flight controller.

Country & Year

Colombia - 2026

Authors

Hernando Leon-Rodriguez
Juan Diego Bayona
Karen Sofia Castiblanco
Juan Sebastian Cruz
Cristian Felipe MontaƱa
Daniel Alejandro Pinzon
Sergio Santiago Sosa
